【SIEMENS】現貨Incremental Encoder 1XP8001-1/1024 (編號:ID:538725-11)

Description

• Manufacturer : Siemens
• 1XP8001-1/1024
• Siemens rotary encoder
• Supply : +10 V to +30 V (HTL)
• Current input without load: 200mA
• Maximum load current per output:100mA
• Resolution, Pulses per revolution:1024
• Pulse offset between the two outputs:90 ± 20%
• Output amplitude: U High> UB-3.5V, U Low< 3V
• Minimum edge interval: 0.8uS at 160 KHz
• Edge sttepness(without load or cable): t+, t-<200 ns
• Maximum frequency : 160 kHz
• Maximum speed : 9000 /MIN; 9000 rpm
• Temperature range -20 C to 100C
• Degree of protection: IP66
• Maximum radial cantilever force: 60N
• Maximum axial force: 40N
• Termination system: 12-PIN
• 12-way plug (socket supplied)
