Compact reader ARE i2 LF
The ARE i2 is a reader unit, which can be integrated in an industrial field bus network. Most PSK and ASK transponder types can be read with this reader (for example 64 bit read only or 1 kbit or 2 kbit read/write transponder). Because of its small outline dimensions, the reader is ideally suited for integration in completely automated production lines.
- ELECTRICAL CHARACTERISTICS
- TROVAN, ISO FDX-B, ISO HDX, ASK r/o – r/w , PSK 1
- 125 kHz, 134.2 kHz
- RS 232, USB, Profibus DP up to 12 MBit/s
- Easy serial ASCII based control protocol
- 9V… 30V
- AAN X1L/F | -X2L | -X3L | -X4L | -X6L | -X9L
- ENVIRONMENT
- -20°C up to +70°C
- -20°C up to +70°C
- IP 65
- IEC 68-2-6 / 29
- DIMENSIONS
- Ca. 170 g
- 90 mm
- 58 mm
- 38 mm
- PA6, ABS
- ADDITIONAL INFORMATION
- Mounting: 2 mounting bracelets or optionally mounting on top hat rail
